If you try to reverse the whole project it will take you a long time to complete the reverse due to the amount of classes (and relationships) are just too many. For details about on demand reverse engineering, refer to the section below.Ĭlick to close the Reverse Code dialog without reversing code.Ĭonsider if you have a project that contains million of C++ source file, and now you want to re-develop just a few classes in it.

Visual studio 2018 c++ make uml code#

The programming language of the source code to reverse.Ĭlick to add a new mapping between source path where code will be reversed from and UML model.Ĭlick to remove chosen source-path-to-model mapping.Ĭlick to move chosen source-path-to-model mapping one item upward.Ĭlick to move chosen source-path-to-model mapping one item downward.Ī list of mapping between UML model and source path.īy checking, this means to form indexes to the source path(s) instead of actually reversing them. Right click on them and select C++ Round-trip > Reverse Code from the pop-up menu.

Visual studio 2018 c++ make uml update#

Once you have performed round-trip engineering for once, you can update specific UML class(es) from source code for reflecting the changes made on that particular class(es) To update, select in class diagram the UML class(es) you want to update. Note: In order to trigger this function, make sure you have performed round-trip engineering at least for once and the diagram has at least one class. To update, right click on the background of the class diagram for update and select Utilities > C++ Round-trip > Reverse Code from the pop-up menu. Once you have performed round-trip engineering for once, you can update UML class(es) on a diagram from source code for reflecting the changes made in code. Updating UML classes on a class diagram from code

Click OK button to proceed with reversal.

If you want to carry out actual reverse engineering, uncheck Reverse source on demand. For details about on demand reverse engineering, refer to the section below.

By default, an on-demand reverse engineering will be carried out, which means to form indexes to the added path(s) instead of actually reversing them.

If you do not use model to structure your project, keep model to be.

You can add multiple Source-path-to-model mapping by pressing the + button. Once a mapping is defined, round-trip engineering will be performed between the model and path as defined. For example, you may create a Prototype model and an Implementation model for storing classes developed in prototype and implementation phrases respectively. You can place the UML classes to be produced to specific model for better categorization. Model is a UML element that acts as a container of other elements.

In the Reverse Code dialog box, specify the mapping between source path and model.

Select Tools > Code > Reverse Java Code… from the toolbar.

You can produce UML classes from source code, or to update from code all the reversed UML classes in project. You can make use of round-trip engineering to keep your implementation model and source code up-to-date, so as to produce up-to-date documentation on your model. Round-trip engineering is the ability to generate model from source code and generate source code from UML model, and keep them synchronized.
